| Models |
916T |
| Video Format |
NTSC/PAL |
| Video Compression |
MPEG4, G723 for audio |
| Internet Transmitting / Compression |
MPEG4 |
| Display Frame Rate |
480/400fps |
| Recording Frame Rate (FPS) |
480(352x240), 240(704x240), 120(704x480) in NTSC/
400(352x288), 200(704x288), 100(704x576) in PAL |
| Display Resolution |
704x480/704x576 |
| Recording Resolution |
NTSC: 704x480, 704x240, 352x240
PAL: 704x576, 704x288, 352x288 active pixels |
| Display Division |
Single / Sequence / Split (1/4/8/16) |
| Video Input |
BNCx16 |
| Video Output |
Monitor/ Spot/ Looping:2CH/1CH/16CH
S-Videox1, VGAx1 (Max 1024x768) |
| Audio In/Out |
16/2 |
| Alarm In/Out |
16(NO or NC) Alarm Input/ 4 NO and 4 NC Relay Out |
| Operation |
Embedded Linux. Recording, Playback, Monitoring, Back up & Network at the Same Time, Keypad, Mouse and Remote Controller |
| Recording Mode |
Continuous / Schedule / Motion Detection / Alarm recording |
| Recording Quality |
Very low, Low, Standard, High, Very High |
| Search Mode |
Date/Time, Motion, Alarm, Manual |
| Storage Support |
Internal 3.5 SATA HDDx4(Max.) |
| Backup Device |
USB stick / CD-RW/DVD±RW (option) |
| Serial Connectors |
USB 2.0x2, Mouse (Combo USB & PS/2 protocol)x 1,
RS485 x 1, IR receiverx1, RS232x1 |
| Network Connection |
10/100 Ethernet(RJ-45) |
| Network Protocol |
TCP/IP, Static IP, DHCP, NTP, SMTP, UDP, HTTP, PPPOE , DDNS
(through Router) |
| Network Remote |
Web(IE)Viewer, Event Notification, Multi-User Accessing, Two Way Audio Support, CMS S/W |
| Remote monitoring, recording, playback and PTZ by Client Program and IE browser. |
| Power Supply |
AC to DC Adapter, 12V, 6.6A (HDDx2) / 8.5A (HDDx4) |
| Dimension(WxHxD) |
430X90X370mm |
| Weight |
5.4kg (W/O HDD) |
|
