Model |
540 |
NTSC |
PAL |
| |
| Video Compression |
MJPEG |
| Video Input |
BNCx4 |
| Video Output |
Video outx2 |
| Display Resolution |
640x448 |
640x544 |
| Display Frame Rate |
120fps |
100fps |
| Display Division |
Single/Sequence/Split(1/4) |
| Audio Input |
1 |
| Audio Output |
1 |
| Recording Resolution |
640x224 |
640x272 |
| Recording Frame Rate(Auto balance) |
60fps |
50fps |
| Recording Mode |
Continuous/Schedule/Motion Detection |
| Recording Quality |
High/Normal/Low |
| Search Mode |
Time/Event |
| HDD Storage |
Internal 3.5” SATA HDD x1 |
| Backup Device |
USB stick |
| USB |
USB 2.0 (Front Panel)x1 |
| Mouse |
Mouse Port (Rear Panel)x1 |
| IR controller |
Yes |
| Mouse |
Yes(Combo USB & PS/2 protocol) |
| Power Supply |
Input:AC100~240V 50/60Hz, Output:DC12V |
| Dimension (WxHxD) |
215x45x 200mm |
