Model

OS-24G8

Image Sensor

1/3" Sony color CCD

Pixels

PAL: 537(H)×597(V)       NTSC: 537(H)×505(V)

Resolution

420TVL

Minimum Illumination

0LUX with IR ON

S/N Ratio

>48dB

Electronic Shutter

NTSC:1/60-1/100,000 second PAL:1/50-1/100,000 Second

Lens

Standard 3.7 mm

Video Output

1.0Vp-p,75Ω,Composite

AGC

AUTO

BLC

AUTO

AWB

AUTO

Scanning system

2:1 Internal

S/N Ratio

＞48dB

Gamma

0.45/1

Sync system

Internal

Power Supply

DC12V 75-350mA

IR distance

25M

-20℃ ~ +50℃ RH95% Max

Size

Standard:Φ60×126(H)mm
